mCove Rectangle

Static White & Dynamic Color

Warm DimTunable WhitePixelRGB/RGBWDamp
Overview
Specifications

mCove Rectangle is a linear luminaire designed for architectural surface and millwork applications where clean lines and visual comfort are essential. It is available with Tunable White LEDs offering precise CCT control, Warm Dim LEDs that smoothly dim from warm to ultra-warm color temperatures. The fixture delivers dot-free, even illumination with a frosted lens and supports linked runs for continuous lines of light. Additional highlights include Self-contained integral power supply eliminates remote driver requirements for a seamless system., Fixtures made to order up to 144” and can be linked together for a continuous run, Suitable for wall mount. mCove Rectangle – Dynamic Color is a linear luminaire designed for architectural surface and millwork applications where clean lines and visual comfort are essential. Additional highlights include Fixtures made to order up to 144” and can be linked together for a continuous run, Suitable for direct view, vanity, and accent lighting applications, Class two listed for damp locations. Proudly assembled in the USA.

  • Output Per: 3287.4 lm/m, 1002 lm/ft, 3391.5 lm/m, 1034 lm/ft, 380.6 lm/m, 116 lm/ft, 4084.6 lm/m, 1245 lm/ft, 423.1 lm/m, 129 lm/ft, 501.8 lm/m, 153 lm/ft, 557.7 lm/m, 170 lm/ft, 623.2 lm/m, 190 lm/ft, 629.8 lm/m, 192 lm/ft, 761 lm/m, 232 lm/ft, 912.1 lm/m, 278 lm/ft, 918.4 lm/m, 280 lm/ft, 974.2 lm/m, 297 lm/ft, 1043 lm/m, 318 lm/ft, 1174.5 lm/m, 358 lm/ft, 1243.4 lm/m, 379 lm/ft, 1295.6 lm/m, 395 lm/ft, 1309.1 lm/m, 399 lm/ft, 1542 lm/m, 470 lm/ft, 1669.9 lm/m, 509 lm/ft, 1712.2 lm/m, 522 lm/ft, 1741.7 lm/m, 531 lm/ft, 2070.2 lm/m, 631 lm/ft, 2086.6 lm/m, 636 lm/ft, 2473.8 lm/m, 754 lm/ft, 2739.5 lm/m, 835 lm/ft, 2755.9 lm/m 840 lm/ft
  • Mounting: Wall
  • Type: Linear Fixture
  • Input Voltage: Line Voltage, Low Voltage
  • CCT: 1800K, 1800K-2400K, 1800K-2700K, 1800K-3000K, 2200K, 2400K, 2700K, 2700K-6500K, 3000K, 3500K, 4000K, 4100K, RGB3000K
  • Color: Pixel, RGB/RGBW, Static White, Tunable White, Warm Dim
  • CRI: 98
  • Wattage Per: 3.3 W/m, 1 W/ft, 32.8 W/m, 10 W/ft, 6.7 W/m, 2 W/ft, 9.8 W/m, 3 W/ft, 13.1 W/m, 4 W/ft, 16.4 W/m, 5 W/ft, 19.7 W/m, 6 W/ft, 23 W/m, 7 W/ft, 26.3 W/m, 8 W/ft, 29.5 W/m 9 W/ft
  • Rating: Damp
  • Lens Aperture: 66 mm 2.60 inch
  • Size: 101.60 mm 4.00 in
  • Height: 31.75 mm 1.25 in
  • Lens: Long Throw Reflector, Tall Throw Reflector
  • Operating Temperature: -20-50 C -4°F to 122°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Manufacturing Details: Made in America
  • Warranty: 7 years
  • Finishes: Black, Paint Ready, White
  • Product Number: MREC_R MREC_INT
