Linear Luminaires

New

Myka Surface Asymmetric – Static White

Static White & Dynamic Color

Warm DimTunable WhiteDamp
Overview
Specifications

Myka Surface Asymmetric is a linear luminaire designed for architectural surface and millwork applications where clean lines and visual comfort are essential. It is available with Tunable White LEDs offering precise CCT control, Warm Dim LEDs that smoothly dim from warm to ultra-warm color temperatures. The fixture delivers dot-free, even illumination with a frosted lens and supports linked runs for continuous lines of light. Additional highlights include 24VDC Class 2 fixtures made to order up to 144”. Fixtures can be linked up to 37’ depending on output, Suitable for undercabinet, millwork, direct view, grazer, vanity, architectural reveals, accent lighting and surface mount. Myka Surface Asymmetric – Static White is a linear luminaire designed for architectural surface and millwork applications where clean lines and visual comfort are essential. Proudly assembled in the USA.

  • Output Per: 337.8 lm/m, 103 lm/ft, 373.9 lm/m, 114 lm/ft, 442.8 lm/m, 135 lm/ft, 492 lm/m, 150 lm/ft, 551.2 lm/m, 168 lm/ft, 557.7 lm/m, 170 lm/ft, 672.4 lm/m, 205 lm/ft, 806.9 lm/m, 246 lm/ft, 859.4 lm/m, 262 lm/ft, 921.7 lm/m, 281 lm/ft, 1036.5 lm/m, 316 lm/ft, 1098.8 lm/m, 335 lm/ft, 1144.7 lm/m, 349 lm/ft, 1158.1 lm/m, 353 lm/ft, 1361.2 lm/m, 415 lm/ft, 1476.4 lm/m, 450 lm/ft, 1512.5 lm/m, 461 lm/ft, 1538.7 lm/m, 469 lm/ft, 1827 lm/m, 557 lm/ft, 1843.8 lm/m, 562 lm/ft, 2184.5 lm/m, 666 lm/ft, 2434.4 lm/m, 742 lm/ft, 2998.7 lm/m 914 lm/ft
  • Mounting: Surface
  • Type: Linear Fixture
  • Input Voltage: Low Voltage
  • CCT: 1800K, 1800K-2400K, 1800K-2700K, 1800K-3000K, 2200K, 2400K, 2700K, 2700K-6500K, 3000K, 3500K, 4000K, 4100K
  • Color: Static White, Tunable White, Warm Dim
  • CRI: 98
  • Wattage Per: 3.3 W/m, 1 W/ft, 6.7 W/m, 2 W/ft, 9.8 W/m, 3 W/ft, 13.1 W/m, 4 W/ft, 16.4 W/m, 5 W/ft, 19.7 W/m, 6 W/ft, 23 W/m, 7 W/ft, 26.3 W/m 8 W/ft
  • Rating: Damp
  • Lens Aperture: 11.2 mm 0.44 inch
  • Size: 20.83 mm 0.82 in
  • Height: 15.494 mm 0.61 in
  • Lens: Black Blade Louver, Clear Lens, Frosted Lens, Half-Frosted Lens, Matte Frosted Lens, White Blade Louver
  • Operating Temperature: -4°F to 104°F, -4°F to 113°F, -20-50 C, -4°F to 122°F, -4°F to 77°F, -4°F to 86°F, -4°F to 95°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Manufacturing Details: Made in America
  • Warranty: 7 years
  • Finishes: Aged Brass, Black, Bronze, Chrome, Matt Black, Polished Gold, Silver Anodized, Warm Nickel, White
  • Product Number: MKA
Available tools: Compatibility Tool
Specsheets
Install Guides
Cross Reference Guide
Myka Surface Asymmetric Static White Specsheet
3.98 MB
PDF
Myka Surface Asymmetric Dynamic Color Specsheet
4.18 MB
PDF
Myka Asymmetric Install
881.02 KB
PDF
Luminii Cross Reference Luminii Optic Arts
PDF
